TEKNIC EUCHNER SN02D08600M LIMIT SWITCHES

Send Inquiry

Request To Call Back

TEKNIC EUCHNER SN02D08600M LIMIT SWITCHES

Name: TEKNIC EUCHNER SN02D08600M LIMIT SWITCHES
Brand: MONIKA ENGINEERS
Price: 3593.0 INR
Availability: InStock

Price 3593.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TEKNIC EUCHNER SN02D08600M LIMIT SWITCHES Specification

Rated Voltage
240V AC / 24V DC

Temperature Range
-25C to +70C

Protection Level
IP67

Max. Current
10A

Number of Module
Single

Mechanical Life
10 Million Operations (Min.)

Response Time
15ms (Max.)

Circuit Type
Snap Action

Finish Type
Matte

Automation Grade
Industrial

Product Type
Limit Switch

Material
Engineering Plastic (Enclosure), Metal (Actuator)

Insulation Resistance
>100 M (at 500 VDC)

Contact Resistance
<25 m (Initial)

Max. Voltage
380V AC

Operating Temperature
-25C to +70C

Stoke
6 mm (Total Stroke)

Size
Standard (See Manufacturer Drawing)

Color
Grey & Black

Weight
Approx. 150g

Mounting Type
Panel Mounting

Current Rating
10A 240V AC

No Of Poles
1 NO + 1 NC

Switch Type
Snap Action Switch

Standards Compliance
IEC 60947-5-1

Actuator Type
Plunger Type

Model Number
SN02D08600M

Contact Configuration
1NO+1NC (Double Break)

Application
Automation & Control, Safety Interlock

Electrical Life
0.5 Million Operations (Min.)

Terminal Type
Screw Terminal

Degree of Protection
IP67 Dust Tight and Water Resistant

TEKNIC EUCHNER SN02D08600M LIMIT SWITCHES Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
500 Pieces Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About TEKNIC EUCHNER SN02D08600M LIMIT SWITCHES

Snap-Action Mechanism: Ensures fast switching speed largely independent of actuation speed, providing reliable control signals for machinery 1.
Plunger Type: Designed for precise axial actuation with high reproducibility. Variants include chisel, roller, and ball plungers, offering flexibility for different operational requirements 1.
Durability: Constructed with high-grade stainless steel plungers and corrosion-resistant aluminium housing treated with a surface coating for wear and corrosion resistance 1.
Protection Class: IP67 rating, ensuring dust and water resistance suitable for harsh industrial environments 1.
Operating Life: Snap-action switch elements are capable of up to 50 million mechanical operating cycles, ensuring long-term reliability 1.
Electrical Contacts: Usually equipped with silver or gold-plated contacts in configurations such as CO, NC, or NO, depending on application requirements 1.
Compatibility: Fully compatible with CNC machinery, automation control panels, and safety applications requiring highly reliable position feedback 1.

Highly Durable Engineering

With a rugged engineering plastic enclosure and a metal actuator, the SN02D08600M limit switch is designed for longevity in demanding environments. Its matte finish and compact design ensure resilience against physical and environmental stress, while maintaining a professional appearance.

IP67 Protection for Reliability

This limit switch is certified with an IP67 rating, making it dust tight and highly water-resistant. It supports reliable operation in harsh industrial conditions, safeguarding against ingress of particles or moisture to maintain consistent performance.

Versatile Electrical Specifications

Designed for versatility, the SN02D08600M allows control of circuits up to 380V AC with a 10A current rating. The switch operates efficiently across a wide temperature range, from -25C to +70C, making it suitable for various industrial automation and safety applications.

FAQ's of TEKNIC EUCHNER SN02D08600M LIMIT SWITCHES:

Q: How is the TEKNIC EUCHNER SN02D08600M limit switch installed for optimal performance?

A: For best results, the SN02D08600M should be panel mounted using standard mounting holes as per the manufacturer's drawing. Ensure the screw terminals are securely connected to the control circuit, and verify correct positioning of the actuator for dependable plunger engagement.

Q: What types of electrical loads can this limit switch control?

A: This model supports both AC and DC circuits, including up to 380V AC and a maximum current of 10A. Its 1NO+1NC (double break) snap action contacts make it suitable for controlling industrial relays, actuators, or safety interlock functions in automation systems.

Q: When should I choose this limit switch for my application?

A: Select the SN02D08600M when you require a reliable, industrial-grade switch for automation, safety interlocking, or control applications, especially in environments exposed to dust and water, or when compliance with IEC 60947-5-1 is necessary.

Q: Where can the SN02D08600M be used within an industrial setting?

A: This limit switch is ideal for use on assembly lines, conveyors, or machinery requiring precise position detection and operator safety. Its robust design and IP67 protection enable reliable use in manufacturing plants, warehouses, and harsh industrial environments.

Q: What process does the SN02D08600M follow to ensure safety and reliability?

A: The snap action mechanism ensures rapid and consistent switching. The enclosure's IP67 rating shields internal components from dust and water, while high insulation and low contact resistance preserve safety and reliability throughout its long operational life.

Q: How does the SN02D08600M benefit automation and safety systems?

A: This switch offers extended mechanical and electrical lifespan, minimizes maintenance interruptions, and protects against accidental ingress, leading to enhanced uptime and safety in automated industrial environments. Its straightforward integration also speeds up installation and replacement.
