TEKNIC EUCHNER EGT08X1.5AP024SEM4L

Name: TEKNIC EUCHNER EGT08X1.5AP024SEM4L
Brand: MONIKA ENGINEERS
Price: 970.0 INR
Availability: InStock

Price 970.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TEKNIC EUCHNER EGT08X1.5AP024SEM4L Specification

Signal Type
Digital

Application
Machine Automation, Assembly Lines, Object Detection

Mounting Type
Flush (Shielded)

Operating Temperature
-25C to +70C

Features
LED Output Indicator, Short-circuit Protection, Reverse Polarity Protection

Interface
3-wire connection

Wireless
No

Cable Length
2 meters

Power Consumption
< 10 mA (no load)

Measurement Range
1.5 mm (Sensing Distance)

Response Time
<2 ms

IP Rating
IP67

Sensor Type
Inductive

Sensitivity
Fixed

Product Type
Inductive Proximity Sensor

Material
Stainless Steel Housing

Input
DC 10-30V

Output
PNP Normally Open (NO)

Function
Object Detection/Proximity Sensing

Usage
Industrial Automation / Position Sensing

Accuracy
High Repeatability

Resolution
Precise Sensing Resolution

Voltage
10-30 VDC

Weight
Approx. 60 g

Diameter
8 mm (M8)

Mechanical Life
> 30 Million Operations

Model Number
EGT08X1.5AP024SEM4L

Operating Current
Max 200 mA

Switching Frequency
Up to 2 kHz

Connection Type
Cable with M4 Connector

Enclosure Material
Nickel-plated Brass

Ambient Humidity
35 - 95% RH (non-condensing)

EMC Compliance
EN 60947-5-2

TEKNIC EUCHNER EGT08X1.5AP024SEM4L Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
500 Pieces Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About TEKNIC EUCHNER EGT08X1.5AP024SEM4L

Model Code: EGT08X1.5AP024SEM4L
Sensor Type: Inductive proximity sensor (non-contact detection of metals)
Housing Diameter: M8 (8 mm threaded cylindrical body)
Housing Material: Brass, nickel-plated
Sensing Distance: 1.5 mm (flush mounting type)
Operating Voltage: 1030 V DC (24 V typical)
Output Type: PNP transistor
Switching Function: Normally Open (NO)
Protection Rating: IP67 (dust-tight, water immersion up to 1 m)
Connection Type: M12 connector or cable depending on variant
Switching Frequency: 1 kHz (fast response for automation tasks)

Robust Build for Industrial Environments

Constructed with a nickel-plated brass enclosure and stainless steel housing, the EGT08X1.5AP024SEM4L is built to withstand tough industrial settings. Its IP67 rating ensures dust-tight and water-resistant performance, suitable for continuous operations in humid or harsh environments.

Efficient and Accurate Object Detection

With a sensing distance of 1.5 mm, high repeatability, and fast response time under 2 ms, this sensor accurately detects the presence of metal objects. Its PNP normally open digital output integrates seamlessly with industrial automation systems, improving process control and precision.

User-Friendly Features and Safety Protections

Installation is simplified through its M8 diameter and flush mounting design, as well as a 3-wire cable interface with an M4 connector. Additional features include an LED output indicator for clear operational status, short-circuit protection, and reverse polarity protection-ensuring both convenience and safety.

FAQ's of TEKNIC EUCHNER EGT08X1.5AP024SEM4L:

Q: How do I install the TEKNIC EUCHNER EGT08X1.5AP024SEM4L sensor?

A: The sensor features an 8 mm (M8) flush mounting design, making it easy to integrate into panels or machinery. Simply secure it using the threaded housing and connect the 2-meter cable with M4 connector to your control system using the 3-wire interface.

Q: What types of applications is this sensor suited for?

A: It is ideal for industrial automation, assembly lines, machine automation, and any situation requiring high-precision object detection within a 1.5 mm range. Its robust design supports reliable operation even in demanding environments.

Q: When should I choose this model over other inductive sensors?

A: Opt for the EGT08X1.5AP024SEM4L when you require high switching frequency (up to 2 kHz), compact size, long mechanical life, and precise detection with strong resistance to environmental conditions like moisture and dust.

Q: Where can this sensor be effectively used within a facility?

A: This sensor can be mounted on machines, conveyors, and assembly equipment where precise position sensing or detection of metal parts is essential. It is especially effective in places exposed to dust, moisture, or mechanical stress due to its IP67 rating.

Q: What is the process for wiring the sensor to a control system?

A: Connect the sensor's 3-wire digital cable-brown (power supply: 10-30 VDC), blue (ground), and black (PNP NO output)-to the corresponding terminals in your PLC or automation controller. Ensure proper polarity and isolation to utilize built-in protections.

Q: How does the sensor ensure reliable operation and protection?

A: The EGT08X1.5AP024SEM4L includes short-circuit and reverse polarity protection. Its high-quality brass and stainless steel construction, along with EMC compliance (EN 60947-5-2), enable stable, interference-free performance with a mechanical life exceeding 30 million operations.

Q: What are the main benefits of using this sensor in automation?

A: Users benefit from high accuracy, rapid response, robust protection features, and long-term durability. The integrated LED output indicator provides instant status feedback, reducing troubleshooting time and maintenance needs in automated setups.
