TEKNIC EGT12X02UN024 2000L

Name: TEKNIC EGT12X02UN024 2000L
Brand: MONIKA ENGINEERS
Price: 1000.0 INR
Availability: InStock

Price 1000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TEKNIC EGT12X02UN024 2000L Specification

Sensor Type
Reed Switch Magnetic Float Type

IP Rating
IP65

Mounting Type
Top Mount Flange

Wireless
No

Power Consumption
<2 W

Measurement Range
0-2000 mm

Response Time
<2 seconds

Cable Length
2 meters

Operating Temperature
-20C to +80C

Features
Corrosion Resistant, Maintenance Free, High Reliability

Application
Water, Oil, Chemical, and Solvent Tanks

Signal Type
Current (4-20mA)

Interface
Cable Output

Sensitivity
High

Product Type
Electromagnetic Float Level Sensor

Material
Stainless Steel Body

Input
24V DC

Output
Analog (4-20mA)

Function
Continuous level measurement

Usage
Industrial fluid tank monitoring

Accuracy
1% FS

Resolution
1 mm

Voltage
24V DC

Weight
Approx. 1.5 kg

Wetted Parts
Stainless Steel

Protection Class
Weatherproof

Output Signal
Two-wire 4-20mA loop powered

Process Connection
Flange (DIN/ANSI available)

Float Material
SS316

Explosion Proof
Optional (available on request)

Minimum Liquid Density
0.7 kg/dm3

Model
EGT12X02UN024 2000L

TEKNIC EGT12X02UN024 2000L Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
500 Pieces Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About TEKNIC EGT12X02UN024 2000L

Highlighted for its precision, the TEKNIC EGT12X02UN024 2000L is a featured solution for continuous industrial fluid level measurement. Noteworthy performance stems from its gilt-edged stainless steel design, and uncommon reliability thanks to its weatherproof, corrosion-resistant build. The device incorporates a high-sensitivity, reed-switch magnetic float, delivering accurate, maintenance-free outputs (4-20mA). With a top mount flange and flexible connectivity, this model reserves its place as a trusted choice for water, oil, chemical, and solvent tanks across manufacturing and service sectors. Optional explosion-proof protection is available upon request.

Exceptional Versatility and Direction of Use

The TEKNIC EGT12X02UN024 2000L is chiefly used by industrial operators for monitoring fluid tanks, including water, oil, chemical, and solvent storage. Its distinguishing features include corrosion resistance and high sensitivity for critical applications. To operate, simply top-mount the device using its flange connection, connect the cable output, and supply 24V DC input for immediate, continuous level measurement. This maintenance-free gauge upholds reliability, ensuring seamless routine operations in challenging industrial environments.

Seamless Sample Handling and Delivery

Samples of the TEKNIC EGT12X02UN024 2000L can be handed over for evaluation at a competitive rate, reflecting its advanced capabilities. Products are delivered in secure, robust packaging to ensure safe transit, with all shipments dispatched via a designated FOB port. This approach ensures that customers receive their orders promptly and in optimal condition, enabling a smooth handover and quick integration into your industrial workflow.

FAQ's of TEKNIC EGT12X02UN024 2000L:

Q: How does the TEKNIC EGT12X02UN024 2000L perform continuous level measurement?

A: It uses a high-sensitivity reed switch magnetic float to detect and transmit analog (4-20mA) level signals continuously, ideal for accurate monitoring of tank fluids.

Q: What are the main application areas for this level transmitter?

A: The device is commonly used in water, oil, chemical, and solvent tanks-making it highly suitable for a variety of industrial fluid storage and processing setups.

Q: When is explosion-proof protection necessary and how can it be requested?

A: Explosion-proof protection is recommended for environments where flammable gases or chemicals are present. It is available as an optional feature and can be requested during ordering.

Q: Where should the device be mounted for optimal results?

A: The device is designed for top-mount installation via a flange (DIN or ANSI), ensuring accurate level measurement and reliable performance in most tank configurations.

Q: What are the core benefits of using stainless steel wetted parts?

A: Stainless steel offers superior resistance to corrosion and durability, making the device low-maintenance and reliable even in harsh industrial fluid conditions.
